250L accumulare Canite CUMATIUM Apparatus

Model:KGB120E

Hoc fixum foramen et claudendo ictu CUMATIUM apparatus, featuring duplex viverra virga synchronous clamping et oleum cylindricum direct pressura obfirmatis densis fingunt, delivers altum perficientur et efficientiam. Equipped cum hydralic servo ratio pro ieiunium responsionem et industria savings, hic 250L accumulare ictu coronam CUMATIUM apparatus praestat producendo amplis products, ex minoribus vasis ad maiores volumina.

Volume: 250LPondus: 28t

Mitte Inquisitionem

depictio producti Specification Application

Latin KGB120E Model, A ducens Accumulator Caput CUMATIUM Apparatus, includit a Moog C crassitudine moderatoris, robot brachium et deorsum flante ratio, enhancing productivity et qualitas. Hoc versatile 250L accumulare ictu CUMATIUM apparatus est specimen Nam variis applications, comprehendo eget tympanum Canite CUMATIUM Apparatus Solutions, plastic gregem clanculum CUMATIUM machina processus, plastic aquae Tank Clowing CUMATIUM Apparatus applications et productionem 200-220l Geminus-anulus cados, currus obterere, auto partes, negotiationis claustra, medicina, supellectilem, natantes buoys, chairs, tables, pallets, naves et magis.

Features et commoda

Propter vestibulum products in variis industrias. Utrum sit magna capacitas corrosio-repugnans continentia in eget industria, packaging utres cum stricte hygiene signa in cibis industria, aut packaging boxes cum exquisitiis quotidianum products, potest esse pressius ad occursum diversimode foro potest esse pressius ad occursum diversimode foro non potest esse pressius ad occursum diversimode forum.
Et pascens processus adoptat secans-ore technology et optimized secundum summus capacitatem productio characteres de 120e Canite CUMATIUM Apparatus. Certe moderari fluunt rate et distribution of rudis materiae ad curare uniformis murum crassitudine per coronam in quantum magna volumine products, efficaciter confirma structuram fortitudinem, et eliminare qualis defectus in inaequalis pascens.

250L accumulate blow molding machine

Specifications

Serial number	Material PE、PP、ABS...	Mold closing oil cylinder(single cylinder)
Serial number	Material PE、PP、ABS...	Machine model:KGB120E
Specifications
1	Max container capacity	250 L
2	Output(dry Cycle)	300 PC/HR
3	Machine Dimension(L×W×H)	7.6 M x 4.3 M x5.5 M
4	Machine weight	28 T
Clamping Unit
1	Clamping force	800 KN-1200 KN
2	Mold platen size(W×H)	1300 MM x 1400MM
3	Platen opening stroke	800 MM-1800 MM
4	Platen moving stroke	700 MM
5	Max mold size(W×H)	1100 MM x 1700 MM
6	Mold thickness	810 MM - 900 MM
Power
1	Servo oil pump motor power	37 KW
2	Servopump displacement	250 L/MIN
3	Blow pressure	0.8 Mpa
4	Air consumption	1.8 M³/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	120 L/min
7	Average energy consumption	80 KW -90 KW
Extruder unit
1	Screw diameter	120 MM
2	Screw L/D ratio	25 L/D
3	HDPEMelting capacit for HDPE	250 Kg/hr-320 Kg/hr
4	Number of heating zone	6 ZONE
5	Screw heating power	30.2 KW
6	Screw fan power	0.6 KW
7	Extruder motor power	90(110) KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	38.8 KW
3	Max die-pin diameter	600(700) MM
4	Accumulator capacity	20(25) L
5	(PE)Accumulator weight	15(18) KG
