1000L IBC aquae obterere cumulare ictu CUMATIUM Apparatus

Model:KGB1000L- IBC

Usus vires et stabilitatem in KGB1000L IBC aquae obterere cumulare ictu CUMATIUM apparatus, featuring an altiore pondus valde LV tons ad minimize tremor et displacement. Diametrum duplex colligationem virgas et centralis tres-cylinder clamping curare etiam accentus distribution trans fingunt, enhancing productio accurate.

Volumen: 1000LWeight: 55T

Mitte Inquisitionem

depictio producti Specification Application

Haec 1000L IBC aquae obterere cumulare ictu CUMATIUM Apparatus incorporat Advanced Flante Technology Principia et multi-iacuit productio pro reducitur costs et improved uber diuturnitatem. Specimen pro producendo magna-capacity continentia, inter aquas piscinam Canite CUMATIUM apparatus Applications, hoc apparatus est specie disposito ad IBC tympana ad 1000l, faciens idoneam ad producendo chemical packaging tympana, magna-amplitudo car oleum tympana, et magis. Contact Us Hodie ad a customized quote et explorare nostri competitive aqua piscinam CUMATIUM Apparatus pretium.

Features et commoda

In altiore apparatu potest pervenire plus quam LV tons, efficacius reducendo tremens et machina displacement, et improvidus productio accurate et stabilitatem.
● Diagonalis duplex colligationem virgas et centralis tres-cylindrici fingunt clamping, in template est magis aequaliter illustraverat et non facile deformis
● Multi-layer productio reducit productio costs et amplio uber diuturnitatem
● apta ad vestibulum magna plastic products ut aqua turres, repono obterere, eget continentia, etc.

1000L IBC water tanks accumulate blow molding machine

Specifications

Serial number	Material PE、PP、ABS、HMWHDPE..	Fixed open- closing type Specialized Machine Series
Serial number	Material PE、PP、ABS、HMWHDPE..	Machine model:KGS1000L-IBC
Specifications
1	Max container capacity	1000 L
2	Output(dry Cycle)	150 L
3	Machine Dimension(L×W×H)	9.5 M x 5.1 M x 6.5 M
4	Machine weight	55 T
Clamping Unit
1	Clamping force	1000 KN
2	Mold platen size(W×H)	1800 MM x 1600 MM
3	Platen opening stroke	1150 MM - 2700 MM
4	Platen moving stroke	950 MM
5	Max mold size(W×H)	1600 MM x 1500 MM
6	Mold thickness	1200 MM - 1400 MM
Power
1	Servo oil pump motor power	25 KW
2	Servopump displacement	250 L/MIN
3	Blow pressure	0.8 Mpa
4	Air consumption	2 M³/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	120 L/min
7	Average energy consumption	110 KW - 150 KW
Extruder unit
1	Screw diameter	100 MM x 2 MM
2	Screw L/D ratio	32 L/D
3	Melting capacit for HDPE	180 Kg/hr x 2 Kg/hr
4	Number of heating zone	6 ZONE
5	Screw heating power	30.2 KW
6	Screw fan power	0.6 KW
7	Extruder motor power	90 KW x 2 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	38.8 KW
3	Max die-pin diameter	450 MM
4	Accumulator capacity	45 L
5	(PE)Accumulator weight	33 KG
